Filling Machine for Gable Top

Filling Machine for Gable Top

Filling Machine for Gable Top

Specifications

LFS(Liquid Food Solution) is dedicated to be a global comprehensive liquid food packaging provider.

  • Capacity

    2000-3000p/h

  • Package Volume

    200ml、500ml、750ml、1000ml、1500ml， Completed on the same machine

  • Packaging material

    Roof cardboard box or roof foil carton

  • Filling temperature

    Cold filling 2-50℃ or hot filling 80-94℃

  • Shelf life

    Depending on product type and process

  • Total power

    15kW (Three Power Electrics)

  • Compressed air

    Flow： 0.8-1.0m³/min， Pressure：1.0-1.4MPa ， Oil-free and dust-free

  • Cooling water

    Flow：≥ 20L/ min， Temperature: normal temperature

  • Dimensions

    4200× 1400×2600mm(L×W×H)

  • Net weight

    2000kg

Product Advantages

LFS(Liquid Food Solution) is dedicated to be a global comprehensive liquid food packaging provider.

  • Easy and fast adjustment

    Digital color display, computer storage, storage of a large number of product operating parameters for product variety change at any time, automatic fault diagnosis, real-time display, arbitrary adjustment and modification of filling parameters.

  • Low failure rate

    The filling valve and the bottle do not move in the up and down direction, the elastic positioning clip is stuck on the bottle neck, the valve mouth and the bottle mouth are centered and positioned, the liquid column can be filled quickly and accurately, and the work is stable and reliable.

  • Run smoothly

    The equipment is reasonably designed, the internal structure is compact, the components work in coordination with each other, and the operation process is stable.

  • High working efficiency

    The equipment is cost-effective, can be customized according to requirements, supports customization, and improves work efficiency and work cycle.
